CRW Works ULTIMO6060 Road Disc Brake Wheelset

Price range: $2,399.00 through $2,449.00

New layup, new spokes, new hub,
NEW STANDARD

  • Weight: 1160g per set (±2%)
  • Spokes: Aero blade carbon spokes
  • Width (External): 32mm front / 32mm rear
  • Width (Internal): 24mm front / 24mm rear
  • Bearings: TPI ceramic bearings
  • Hub System: 45T star ratchet
  • Rims: UD paintless finish
  • Decals: Choice of black or white

No reviews yet.
SKU: CRW-UT-6060 Categories: ,

Description

NEW LAYUP, NEW SPOKES, NEW HUB,

NEW STANDARD.

The CRW ULTIMO is CRW’s latest flagship carbon road wheelset, developed to deliver a refined balance of aerodynamic efficiency, stiffness, low weight and long-term durability.

Designed for modern performance road bikes and race-focused riders, the ULTIMO combines an advanced carbon construction with a contemporary aero profile, optimised around wider tyres and modern frame platforms.

Whether you are attacking fast group rides, racing criteriums or climbing mountain passes, the ULTIMO is built to deliver unwavering performance, every time.

KEY FEATURES

Advanced Aero Rim Profile

The ULTIMO wheelset features an aerodynamic rim profile designed around modern wide road tyres and contemporary aero framesets.

Available with 50mm or 60mm front rims paired to a 60mm rear, the profile has been developed to balance aerodynamic efficiency with predictable handling and crosswind stability in real-world riding conditions.

An improved spoke design and a low spoke count further enhance the crosswind stability and reduce aerodynamic drag at higher speeds.

Lightweight and Stiff Carbon Rim Construction

Built using high-grade carbon fiber and a new optimized layup, the ULTIMO rim minimizes weight without sacrificing the stiffness and strength required for high-performance riding.

This refined construction delivers high lateral stiffness and efficient power transfer, allowing the wheelset to accelerate quickly, climb efficiently, and hold momentum at speed.

Additionally, the tuned layup preserves the smooth ride quality and long-term durability, resulting in a lightweight wheelset that remains solid and dependable under the hardest riding conditions.

High-Engagement Performance Hub

At the center of the ULTIMO is a high-performance hub system engineered for exceptional rigidity, smooth rolling, and long-term durability. By combining an oversized bearing structure with an increased driving flange diameter, the hub maximizes structural integrity and power transfer.

This design is paired with a 45-tooth integrated ratchet mechanism that delivers rapid engagement and superior transmission efficiency, ensuring an instantaneous, direct pedal response under intense acceleration and high-torque efforts.

Bespoke Carbon Spokes

The ULTIMO features an updated carbon fiber spoke designed to reduce rotational weight while improving responsiveness and ride feel.

Their narrow aerodynamic profile minimizes drag to enhance high-speed stability and airflow management, while the carbon construction maintains optimal wheel stiffness without creating an excessively harsh ride.

Furthermore, a precision preload system effectively offsets tolerances and compression from thru-axle clamping, eliminating axial pressure on bearings to significantly extend service life, all supported by reinforced titanium spoke interfaces for maximum strength and durability.

Specifications

CRW ULTIMO 50|60

2026 UT 5060

Brake Type: Disc
Weight: 1150g ±2%
Front wheel
    Rim Depth: 50mm
    Internal Rim Width: 25mm
    External Rim Width: 34mm
    No. of Spokes: 16
    Min. Tire Size: 28mm
    Max. Tire Size: 45mm
    Max. Tire Pressure: 100psi or tire's maximum pressure. (Whichever is lower.)
    Thru Axle Size: 100 x 12mm
Rear wheel:
    Rim Depth: 60mm
    Internal Rim Width: 24mm
    External Rim Width: 32mm
    No. of Spokes: 20
    Min. Tire Size: 28mm
    Max. Tire Size: 45mm
    Max. Tire Pressure: 100psi or tire's maximum pressure. (Whichever is lower.)
    Thru Axle Size: 142 x 12mm
Tubeless compatible, Hooked rim.
Freehub:
45T Star Ratchet. Shimano 11s, SRAM XDR or Camp. compatible options.

CRW ULTIMO 60|60

2026 UT 6060

Brake Type: Disc
Weight: 1160g ±2%
Front wheel
    Rim Depth: 60mm
    Internal Rim Width: 24mm
    External Rim Width: 32mm
    No. of Spokes: 16
    Min. Tire Size: 28mm
    Max. Tire Size: 45mm
    Max. Tire Pressure: 100psi or tire's maximum pressure. (Whichever is lower.)
    Thru Axle Size: 100 x 12mm
Rear wheel:
    Rim Depth: 60mm
    Internal Rim Width: 24mm
    External Rim Width: 32mm
    No. of Spokes: 20
    Min. Tire Size: 28mm
    Max. Tire Size: 45mm
    Max. Tire Pressure: 100psi or tire's maximum pressure. (Whichever is lower.)
    Thru Axle Size: 142 x 12mm
Tubeless compatible, Hooked rim.
Freehub:
45T Star Ratchet. Shimano 11s, SRAM XDR or Camp. compatible options.

Additional information

Freehub Type

Shimano HG Compatible, Sram XDR Compatible, Campagnolo 10-12 Speed Compatible, Campagnolo N3W Compatible

Decal Color

Black Decals, White Decals

Spare Spoke

YES ($50.00), NO

Brand

CRW Works

Brand Name: CRW Works Chinese Company Name: 厦门铠富特运动科技有限公司
Founded: 2021 # of Employees: 5-10
Headquarters: Xiamen, Fujian Products Categories: Wheels
While unknown in the west, Craft Racing Works (CRW) have been quietly building wheelsets for other companies since 2015. They launched their own brand in 2018 and in 2020 started designing their own hubs. They’re a small team who pay attention to the details. They put an emphasis on the performance of the wheelset as a whole as opposed to individual components. They often experiment with new technologies such as Berd spokes and aren't afraid to try new things. As a new brand with a limited number of wheels out on in the wild, it's hard to give them a rating for durability or longevity. As always, early adopters take the risk of being a guinea pig, but the advantage is that you get a great performing wheelset at a great price before the brand raises prices due to the overheads of being a larger brand. There is a manufacturer's warranty with the wheels, so that does provide some peace of mind.
